AMF PANEL
Product Details:
- Base Material Other
- Material Other
- Click to view more
-
Share Your Product:
X
AMF PANEL Price And Quantity
- 1 Piece
AMF PANEL Product Specifications
- Other
- Other
AMF PANEL Trade Information
- Gujarat Maharashtra Madhya Pradesh Rajasthan
Product Description
An AMF Automatic Mains Failure panel is an essential component in power management systems particularly for standby generator setups It automatically manages the transition between the main power supply and a backup generator in case of a power failure Heres a detailed technical description
Components
1 Input Power Sources
Mains Power The primary source from the electrical grid
Generator Power The secondary source usually a diesel or gas generator
2 Automatic Transfer Switch ATS
A crucial part of the AMF panel that facilitates the seamless switch between mains and generator power
3 Control System
Microprocessor or programmable logic controller PLC that monitors voltage frequency and overall system status
Controls the operation of the ATS based on predefined parameters
4 Monitoring Displays
Digital or analog displays showing voltage current frequency and operational status
Indicators for alarms and fault conditions eg low oil pressure high temperature
5 Alarms and Notifications
Audible and visual alarms to alert operators of system issues or failures
6 Battery Charger
Ensures that the generators starting battery is charged and ready for operation
7 Enclosure
Weatherproof or dustproof housing to protect the internal components
Operation
1 Normal Operation
The AMF panel continuously monitors the mains supply Under normal conditions the load is supplied by the mains power
2 Detection of Mains Failure
Upon detecting a failure in the mains supply voltage drop outage etc the control system activates the generator start sequence
3 Generator Startup
The AMF panel allows the generator to warm up and stabilize This ensures its ready to take the load
4 Transfer to Generator Power
Once the generator is stable the ATS transfers the load from the mains to the generator
5 Restoration of Mains Power
When the mains supply returns and stabilizes the AMF panel switches the load back to the mains
The generator is then put on standby mode ready for the next outage
Applications
Used in critical infrastructure such as hospitals data centers telecommunications and industrial facilities where power reliability is crucial
Standards
Designed to meet national and international standards eg IEC 60947 UL 1008 for safety and performance
Advantages
Ensures minimal downtime during power outages
Automates the process of switching between power sources
Enhances the reliability of power supply systems
This technical description highlights the functionality and importance of AMF panels in maintaining a reliable power supply If you need more specific details or have any particular aspects in mind feel free to ask
